Short Update - Card Sorter Prototype - Sorter table
Original size and arrangement of the 22 boxes!
I will create a huge ball bearing. Because of the
big number of boxes, the diameter must be
around 0.9m. The boxes will orbit around the
feeder and scanner which will sit in the center
in an elevated position.
What’s next?
I will work on the ball bearing.
Servus and cu next time!
Replies (2)
Looks cool! Are you planning on turning it with a motor, stepper motor perhaps?
Btw: I really like your stylish pictures with the black background. :D
Hi, thanks.
Yes you're right. I will use a stepper or a dc-motor with encoder to turn and control the table.
Thanks. I like it also. But I tried a lot of backgrounds until i found one.
It's a ECOBRA Cutting Mat
